Basic Info.
Model NO.
Plus5E-S1200AU
Standby UPS
Sine Wave Output UPS
Output Capacity
Small Type
Equipment Mode
Centralized Model
Brand
Aplus Power
Function
UPS+AVR
Transport Package
Ocean Freight
Specification
1200VA/720W
Origin
China
HS Code
8504402000
Production Capacity
2500PCS/Month
Product Description
Specifications: | MODEL | Plus5E-S1200 |
| CAPACITY | 1200VA/720W |
| INPUT | |
| Voltage Range | -30%, +25% |
| Frequency | 50Hz or 60Hz (Auto-sensing) |
| OUTPUT | |
| Voltage Regulation | +/-10% |
| Frequency | AC mode: 47-53Hz for 50Hz or 57-63Hz for 60Hz ; Battery mode: 50Hz or 60Hz +/-1Hz |
| Waveform | Simulated Sinewave |
| Transfer Time | <6ms (Typical) |
| Smart USB Charging | 2 ports, 5VDC 2.4A max. |
| BATTERY | |
| Type | Maintenance free sealed lead-acid battery |
| Voltage | 24VDC |
| Capacity & Number | 12V/7AH*2pcs |
| Recharge Time | 5 hours to 90% after complete discharge |
| Safety Protection | Over Charge & Over Discharge Protection |
| Advanced Battery Management | Yes |
| DISPLAY | |
| LED Indicators | AC Normal (Green), Battery backup (Yellow), UPS cut off / Fault (Red) |
| AUDIBLE ALARM | |
| Battery Mode | Two short tones every 8 seconds |
| Low Battery | Four short tones every second |
| Overload | Beeping continuously |
| Fault | Beeping continuously |
| ENVIRONMENT | |
| Operating Temperature | 0°C-40°C (32°F-104°F) |
| Humidity | 0-95% (Non-condensing) |
| Acousitc Noise | <40dB at 1M |
| PHYSICAL | |
| Dimension (D*W*H) | 343*135*208mm |
Model Table:
| Model Name | Input Voltage | Outlet | Socket Type |
| Plus5E-S1200UN | 220/230Vac | EURO-US*4pcs Backup/AVR/Surge protected + 4pcs Surge protected only | EURO-US |
| Plus5E-S1200G | 220/230Vac | Schuko(Type F)*2pcs Backup/AVR/Surge protected | Schuko |
| Plus5E-S1200R4 | 220/230/240Vac | Universal*2pcs Backup/AVR/Surge protected | Universal |
| Plus5E-S1200UK | 220/230/240Vac | UK(Type G)*2pcs Backup/AVR/Surge protected | UK |
| Plus5E-S1200AU | 220/230/240Vac | Australian(Type I)*2pcs Backup/AVR/Surge protected | Australian |
| Plus5E-S1200IEC | 220/230Vac | IEC-320 C13*4pcs Backup/AVR/Surge protected | IEC-320 C13 |
| Plus5E-S1200F | 220/230Vac | French(Type E)*2pcs Backup/AVR/Surge protected | French |
| Plus5E-S1200SA | 220/230Vac | South Africa(Type M)*1pc+IEC-320 C13*1pc Backup/AVR/Surge protected | South Africa+IEC-320 C13 |
| Plus5E-S1200IT | 220/230Vac | Italian(Type L)*4pcs Backup/AVR/Surge protected | Italian |
