Basic Info.
Model NO.
DBRY-320
Structure
Stacked
Application
Flexible Packaging Printing
Automatic Grade
Automatic
Printing Speed
55--75m/Min
Max. Unwinding Width
350mm (From 200-900mm Is Optional)
Max. Printing Width
320mm
Max. Unwinding Diameter
600mm
Max.Rewinding Diameter
600mm
Printing Girth
175-580mm
Precision of Chromatography
±0.10mm
Dimensions
L3100mm*W2100mm*H2400mm
Machine Weight
About 3550kg
Transport Package
by Seaworthy Woodencase
Specification
CE
Trademark
DB
Origin
Ruian Zhejiang
HS Code
8501109101
Production Capacity
10set/Month
Product Description
Application: It is widly used for printing narrow material (mainly 320mm, and can adapt to 850mm or wider acc ording to your requirements), and it 's an ideal machine for printing narrow size label etc.
Suitable Material:
Self Adhesive paper, Self -Adhesive Film, Laminating Film, Paper, Opp, Alumium, CPP, PET
Characteristics:
1. Adopt the anilox rollers to spread ink.
2. Unwinding and rewinding controlled by magnetism power brake, clutch.
3. Printing unit adopt 360º To regulate for registration.
4. Each printing unit has one IR drier, and can change to UV, which is more expensive and.
5. The rubber roller can break away automatically while parking, and running at a low speed, in order to avoid water being dried.
6. The main motor is adopted the import stepless regulation of frequency conversion.
7. Unwinding, printing, varnishing, IR drying, laminating and rewinding can be finished in one process, this kind of printing machine is suitable for each printing companies to print on adhesive-paper labels and other commercial label.
8. Meter counter can set printing quantity according to the requirement. Stop the machine automatically at the set quantity or when the material is cut off.
Technology Parameter:
| 1.Printing speed: | 55--75m/min |
| 2.Printing color | 4 colors (1-10colors is optional) |
| 3.Max. unwinding width | 350mm (From 200-900mm is optional) |
| 4.Max. Printing width | 320mm |
| 5.Max. unwinding diameter: | 600mm |
| 6.Max.rewinding diameter | 600mm |
| 7.Printing girth | 175-580mm |
| 8.Precision of chromatography | ±0.10mm |
| 9.Dimensions | L3100mm*W2100mm*H2400mm |
| 10Machine weight | About 3550KG |
| 11.Total power | 38 kw |
Wenzhou Daba Machinery Co., Ltd.as a professional manufacturer of all kinds of label equipment, was established more than ten years ago. Our company consists of Technical Development Department, Manufacturing Department, Domestic and International Sales Department and After-Sales Service Department.Our main products include: Self adhesive label production line (adhesive label flexo printing machine, label die cutting machine, label slitting machine), laminating and coating machine (adhesive label coating machine) rotogravure printing machine, high speed rotogravure printing machine, PVC shrinkable label machine (PVC sleeve label sealing machine, PVC sleeve label inspection machine, label cutting machine) slitting machine, gift paper wrapping machine, gift paper rewinding machine, wallpaper wrapping machine, etc.
For over 10 years, our company has been a leader in Chinese label equipment area. Especially, the self-adhesive label production line are leading.
Now, we have got ISO9001 Quality Management System Certificate and some products have got CE Certificate.
Through our continuous research and development, advanced skills, and a strong commitment to customer service, we have firmly established ourselves as a dependable supplier of China. No matter whether you are looking for a single machine or a whole production line, you can get outstanding machines and know-how results from our technical department.
Every DaBa machine is quality proven, superior in design and produced as per the highest quality standards. Before leaving our factory, it is tested and retested for performance, productivity and durability. Because of good quality and service, we have won a good reputation among domestic and international customers.
Our products sell well in Asia (such as India, Thailand, Vietnam, Indonesia, Malaysia, Sri Lanka), the Middle East (Iran, Pakistan), Europe (Russia, Bulgaria, Croatia, Rumania, Spain, Italy), Africa (Nigeria, Guinea, Congo), North America and South America.
We hope to establish good and long-term business cooperation with customers from all over the world. If you have any inquiry about our machines, please feel free to contact us.
Q: What's your delivery date?
Q: Terms of payment?
A: We accept T/T, 30% in advance and 70% balanced against B/L copy.
We accept L/C at sight.We accept Cash.
Q: How many days will you finish installing ?
A: We will finish installation and training within 15days.
Q: How long is your machine's warranty period?
A: All our machine have one year guarantee, starting from finished installation.
Q: How could we do after one year warranty period?
A: We also can do service for you, however, if require overseas service, you need pay salary to our technician 100 USD/day.
Q: How could we do if the parts broken within warranty?
A: We would express the free replacement parts during the warranty date.
Q: How many worker do we need running those machines?
A: For flexo printing, slitting, die-cutting machine, only need one person for each.
Q: What should we charge for your engineer?
A: You should charge for the cost of our engineer's visa , air tickets, hotel, food ,and also their salary 100USD one day per person.
