Basic Info.
Model NO.
GMD-60, GMD-80, GMD-100, GMD-150, GMD-200, GMD-230
Separation Mode
Sedimentation Type
Operating Type
Continuous Type
Installation
Vertical
Distillation Equipment Type
Molecular Distillation Equipment
Pressure
High Pressure
Condition
New
Effective Evaporation Area (M2)
0.06m2-0.5m2
Designed No-Loading Vacuum
0.001 Mbar
Barel Diameter (mm)
60mm-230mm
Distillate Receiving Flask (L)
1L-10L
Residue Receiving Flask (L)
1L-10L
Feeding Flask Volume (L)
1.5L-5L
Feeding Rate (Kg/H)
0.1kg/H-25kg/H
Operation Temperature
up to 300ºC
Motor Power (W)
120W-200W
Rotation Speed (Prm)
300prm-450prm
Power Supply
220V/50~60Hz (Other Options Can Be Provided)
Transport Package
Wooden Box Package
Trademark
BOTH
Origin
China
HS Code
8419899090
Production Capacity
1000/Year
Product Description
| Model | GMD-60 | GMD-80 | GMD-100 | GMD-150 | GMD-200 | GMD-230 |
| Barel Diameter (mm) | 60 | 80 | 100 | 150 | 200 | 230 |
| Effective Evaporation Area (m2) | 0.06 | 0.1 | 0.15 | 0.25 | 0.35 | 0.5 |
| Feeding Rate (kg/h) | 0.1~2 | 0.1~4 | 0.2~6 | 0.5~8 | 0.5~15 | 0.5~25 |
| Feeding Flask Volume (L) | 1.5 | 1.5 | 1.5 | 2 | 5 | 5 |
| Distillate Receiving Flask (L) | 1 | 1 | 2 | 5 | 10 | 10 |
| Residue Receiving Flask (L) | 1 | 1 | 2 | 5 | 10 | 10 |
| Motor Power (W) | 120 | 120 | 120 | 120 | 120 | 200 |
| Rotation Speed (PRM) | 450 | 450 | 450 | 450 | 300 | 300 |
| Designed No-loading Vacuum | 0.001 mbar | |||||
| Operation Temperature | Up to 300ºC | |||||
| Power Supply | 220V/50~60Hz (Other Options Can Be Provided) | |||||
GMD-A Series : Wide Application, Most Materials
GMD-B Series : High Melting Point, High Boiling Point Materials
GMD-C1 Series : Heat Sensitive, Good Fluidity of Neutral Materials
GMD-C2 Series : High viscosity, High Melting Point, High Boiling Point Materials
GMD-Plus Series : Suitable for All Materials.
·The Lowest Cost to Meet the Requirements of Laboratory R&D Stage
· High Vacuum (0.01mbar/1Pa), Suitable for Separation and Purification of Most Materials
· Visible the Whole Working Process,Experiments Condition Can be Adjusted In Time to Save Users' Precious Time
· No-Stop Continuous Feeding, Continuous Receiving to Test The Performance of Materials in Different Conditions
· Compact Design, Installation Space Saving. Removable Whole Set, Convenient Operation
·Upgrade the Condensing System, Improve the Vacuum & Distillation Temperature
· High Vacuum (0.001mbar/0.1Pa) & High Distillation Temperature (300°C), Suitable for Separation and Purification of Materials with High Melting Point and High Boiling Point
· Completed Closed High Temperature Circulator, Smokeless and No Smell, No Pollution
· Dual Condensation System, Not Only with Fractionation Distillation, But also can Effective Protect Vacuum System
· No-Stop Continuous Feeding, Continuous Receiving to Test The Performance of Materials in Different Conditions
·Upgrade to Full Jacket and Heating Tracing of the Whole Process. Automatic Continuous Feeding & Discharging
· Feed Pretreatment Adopts Heating Plate Instantaneous Heating, Which Is Suitable for Neutral Materials with Heat Sensitivity & Good Fluidity
· Completed Closed High Temperature Circulator, Smokeless and No Smell, No Pollution
· Dual Condensation System, The Closed Type Coil Cold Trap Instead of Traditional Open Cold Trap to Reduce The Consumption
· Continuous Feeding and Discharging, Maintain the System Constant Vacuum, Realize Pilot Scaled Continuous Production
· Upgrade to Full Jacket and Heating Tracing of the Whole Process. Automatic Continuous Feeding & Discharging· Heating Tracing During the Whole Process, Suitable for Materials with High Viscosity, High Melting Point and High Boiling Point
· High Power Disc-haring Gear Pump with Heat Preservation, Avoid Coking & Blocking
· Completed Closed High Temperature Circulator, Smokeless and No Smell, No Pollution
· Dual Condensation System, The Closed Type Coil Cold Trap Instead of Traditional Open Cold Trap to Reduce The Consumption
· Continuous Feeding and Discharging, Maintain the System Constant Vacuum, Realize Pilot Scaled Continuous Production
GMD-Plus SeriesNew Upgrade Solution, Suitable for All Materials.
· Heating Tracing During the Whole Process, Suitable for Materials with High Viscosity, High Melting Point and High Boiling Point
· New Design Structure, Lower Feeding Height, More Convenient for Operation
· Enlarge the Feeding Tank Capacity, Saving the Pretreatment Time
· Equipped with Mini-Adjustable Vacuum Valve, User can Adjust The Vacuum Degree in Real Time
· Variety of Optional Vacuum Configurations, Such as Diffusion Pump, Turbo Molecular Pump, Roots Pump, Dry Screw Vacuum Pump, Etc., to Adapt to All Kinds of Materials
