Basic Info.
Trademark
EASTAR
Origin
Yangzhou City, Jiangsu Province
HS Code
9405409000
Production Capacity
50000 PCS/Month
Product Description
Only DC Output
Specifications
| Power | 210W | 220W | 230W | 250W |
| Solar Panel | 18V 10W | 18V 20W | 18V 30W | 18V 50W |
| Battery | 12V 7AH | 12V 12AH | 12V 17AH | 12V 20AH |
| LED bulb | 3W * 2pcs with 4M cable and switch | 3W*2pcs & 5W*2pcs with 4M cable and switch. | 3W*3pcs & 5W*3pcs with 4M cable and switch | 3W*3pcs & 5W*3pcs with 4M cable and switch |
| USB output | 5V/1A*2 | 5V/1A*2 | 5V/1A*2 | 5V/1A*2 |
| Function | USB, MP3,FM | USB, MP3,FM | USB, MP3,FM | USB, MP3,FM |
DC Appliances (Optional)
DC Output and AC Output
Specifications
| Model | 500W | 1000W | 3000W | 5000W | |
| Battery rated voltage(VDC) | 12 | 24 | 48 | 48 | |
| Inverter | Rated Power(W) | 500W | 1000W | 3000W | 5000W |
| Input voltage range(VAC) | 140-275 | ||||
| Input frequency(Hz) | 45-65 | ||||
| Output voltage(VAC) | 220 | ||||
| Output frequency(Hz) | 50/60 | ||||
| Output wave | Sine Wave | ||||
| Specification of built-in Lithium battery | 600WH | 1200WH | 2600WH | 4500WH | |
| Controller | Rated charge current(A) | 20A | 20A | 30A | 30A |
| Control Mode | MPPT | ||||
| DC output | 5VDC USB output | 2/MAX 2A | |||
| 12VDC output ports | 2/MAX 2A | ||||
| Heat dissipation/Cooling | Temperature control by intelligent exhaust fan | ||||
| Operating ambient temperature | -20 - +50 | ||||
| Storage ambient temperature | -25 - +55 | ||||
| Operating/Storage ambient | 0-90% No condensation | ||||
Application
